Specification

Performance Parameters

Light Sources

White LED lighting when decoding, gradient lighting wiht distance, laset cross indication

Supported Symbologies

1D: UPC-A, UPC-E,Code 39, Code 93, Code32, Code 128, EAN-8, EAN-13, Codabar, Interleave 2 of 5, ISBN, ISSN, MSI-Plessey, Code 11, Industrial 25, IATA25, Matrix 2 of 5.

2D: QR Code, Data Matrix, Micro QR, PDF417, Micro PDF417, Aztec.

Scanning Principle

Image CMOS 1MP

Resolution

1280*800 Pixels

Scan Method

Manual/Continuous/Automatic inductive scanning

Scan Angle

Yaw 45°, Rotation 360°, Pitch 45°

Field of view

48°(H) * 36°(V)

Precision

≥3mil

Contrast

≥15%

Depth of scan field

EAN-13: 4-55cm

Error Rate

Less than 1/5million

Interface

Receiver: USB Type C-HID; Bluetooth: HID, BLE, SPP

Communication Mode

Pairing Mobile Bluetooth Device

Transmission Distance

15M (Open area)

Storage Mode 50,000pcs off-line scanning.

Pairing Mode

One to One: One Scanner Pairs One Receiver,

One scanner paired with a bluetooth mobile device.

Prompt Function

1. power prompt  2. connection prompt

Receiver:

Delicated Bluetooth flash drive receiver,Windows, Android/IOS mobile devices

Physical  Parameters

Dimensions

153mm*36mm*69mm

Weight

120g

Material

ABS+PC

Cable Length

1M

Environmental Parameters

Operating Temperature

-20℃ ~50℃

Storage Temperature

-40℃~70℃

Relative Humidity

5%~95% RH（Non-condensing）

Ambient lighting

0~100000LUX

Drop/Shock Resistance

Withstands multiple times 3 meters drops to concrete

Electrical Parameters

Voltage

DC5V±5%

Operating Current

when not scanning code ≥26mA; when scanning code ≥250mA

Standby Current

0mA(Standby is to cut off battery power)

Charging Mode

Square USB charging cable, plug straight charge

Battery Working Time

up to 48h

Charging Time

3-4.5h

Lithium battery

25000mAh

Charging Model

TypeC charging cable, plug-in direct charging
